Medical Film Sealing

NEW MEDSEAL® - MSIDV + ATC/ALK

Electrically driven medical industrial validatable impulse sealer with integrated Audion Temperature Controller (ATC)

1. Seal width: 8 mm
2. Seal length: 460 | 610 mm
3. Type of seal: Temperature-, time- and pressure controlled impulse seal
4. Powered: Electric
5. Operation: LCD Key Panel (ALK) / 10 pre-set seal recipes
6. Validatable: Yes
7. Vacuum & gas flush system: No
8. Compatible with: EN868-5, section 4.3.2. and DIN 58953 part 7 and ISO 11607-1
9. Accuracy: +++

Contimed D 662 MV

Rotary medical sealer with complete control of sealing parameters

1. Validatable: Yes
2. Seal width: 12,5 mm multiline
3. Throughput: 8 meter/minute (fixed)
4. Control panel: LCD, 2 lines, membrane keyboard
5. Interface: USB port
6. Integrated printer: No
7. Conveyor belt: Optional

Contimed D 666 MPCV

Advanced medical rotary sealer with integrated printer, optimized traceability features

1. Validatable: Yes
2. Seal width: 15 mm multiline seal
3. Throughput: 10 meter/minute (fixed)
4. Control panel: 2 lines LCD, membrane keyboard
5. Interface: COM port RS232 / USB port
6. Integrated printer: 9 dots matrix, 1 line
7. Conveyor belt: No

Contimed D 775 MPCV

Advanced medical rotary sealer with integrated 2 line printer, optimized connectivity

1. Validatable: Yes
2. Seal width: 15 mm multiline seal
3. Throughput: 3 to 13 meter/minute (adjustable)
4. Control panel: Touchscreen, 24 seal recipe memory
5. Interface: 3x USB /2x RS232 /1xEthernet/1x PS2/1xVGA
6. Integrated printer: 18 dots matrix, 2 lines
7. Conveyor belt: No
