IST MED 520

Stainless steel table top impulse sealer for sealing flexible synthetic packages. Seal- and cooling time are separately adjustable to suit the type of material. The IST is equipped with upper and lower sealing bars.The upper sealing bar can be switched off when using a relative thin laminates. Switching between one or two sealing bars is easily done through the operation panel. The impressive seal quality, makes this machine suitable for many different applications also for users of “special laminates”.

This sealer is suitable for use in validated processes.

Standard features

  • Strong price – quality ratio
  • Heavy duty design
  • Sealing length up to 1020 mm
  • Large seal bar opening 45 mm
  • 1 program for the MED models
  • User friendly digital panel
  • Bi-active sealing bars suitable for laminates and thick pouches
  • Equipped with temperature controller
  • Machine can be equipped with support stand
  • Horizontal and vertical sealing position in combination with support
  • Pneumatically closed sealing bars (no overheating of electro magnets)
  • Machine built according to the latest directives

Options

  • Work table
  • Floor stand
  • Stretch fingers
  • Knife / Cutting device (please ask for specifications)

Specifications

ProductIST MED 520
Seal length520 mm
Seal width8 mm
Type of machine
Impulse sealer, Validatable/calibratable/medical
ModelTable/Floor
CoveringStainless Steel
KnifeOption
Pedal operatedYes
Type of filmReady Made Bags, PVC, PP (Polypropylene), PE (Polyethylene), Aluminium Laminated Bags, Medical Pouches, Laminated Film
Thickness of film2 x 200 micron
Type of packageBag
Branche/ApplicationPharmaceutical Industry, Medical Industry
Type of productFluid, Granulate, Powder, Solid
